The Logix control platform is scalable and multidisciplined, so you can apply it plant-wide for process, discrete, motion and drive control, while also delivering your safety and information requirements. Address all of your automation needs with the right Network Connectivity EtherNet/IP (I/O Control & messaging), ControlNet, DeviceNet, DH-485 CompactLogix For your smaller, machine-level control applications, the CompactLogix platform, combined with Compact I/O, provides unprecedented power and scalability. And thanks to its flexible I/O structure, CompactLogix processors can handle some very daunting control tasks for even the most ambitious applications. The CompactLogix platform is a powerful, small Logix5000™-based control system with three processor types offering up to 1.5 Mbytes memory. • Compact form factor and rack-less design – compatible with the full range of 1769 Compact I/O products – provide a truly scalable modular system • Uses the same RSLogix 5000 programming environment as other Logix5000 controllers ............................................. ............................................................................................................................................... Network Connectivity EtherNet/IP (I/O control and messaging), ControlNet, DeviceNet, Remote I/O, DH+, DH485 ControlLogix If high performance in an easy-to-use environment is your goal, ControlLogix controllers could be your ideal solution. With four memory options up to 8Mbyte, ControlLogix supports intensive process applications, and provides fast processing of motion instructions. The broad range of memory options allows you to specify the appropriate controller for your application. • Provides a modular, high-performance control platform suited for sequential, process, drive, and motion control in any combination • Allows you to mix multiple processors,networks, and I/O without restrictions • Uses the same RSLogix 5000 programming environment as other Logix controllers • Connects to the NetLinx Open Network Architecture for more efficient communications and increased throughput • Certified by TUV for SIL 1 and SIL 2 applications ............................................. ............................................................................................................................................... Network Connectivity EtherNet/IP (I/O control and messaging), ControlNet, DeviceNet, Remote I/O, DH+, DH485 FlexLogix With up to 512 Kbyte memory, the FlexLogix platform takes the system-level capabilities of ControlLogix controllers and puts them close to your machine. The FlexLogix processor is a small, highly adaptable, distributed control option that has both local and networked I/O capability. By reducing field wiring, the FlexLogix system decreases your startup costs, improves local I/O performance and simplifies maintenance. • Adds local control to Flex I/O • Provides a less vulnerable distributed architecture because control does not depend on a single master controller • Reduces startup and simplifies maintenance • Uses the same RSLogix 5000 programming environment as other Logix controllers • Connects to the NetLinx Open Network Architecture for more efficient communications and increased throughput ............................................. ............................................................................................................................................... Network Connectivity EtherNet/IP (messaging), ControlNet, DeviceNet,other networks SoftLogix 5800 SoftLogix 5800 combines a high performance Logix control engine with the power and openness of your PC for a reliable open, PC-based control solution with improved flexibility, connectivity and information integration. With SoftLogix 5800, you can truly link the production area “shop floor” with the front office “top floor”. Control, motion, Human Machine Interface (HMI), and information processing now come together in an integrated solution for lower system integration costs and increased productivity. • Supports Windows® NT/Windows® 2000 • Allows you to mix multiple processors, networks, and I/O without restrictions • Uses the same RSLogix 5000 programming environment as other Logix controllers • Connects to the NetLinx Open Network Architecture for more efficient communications and increased throughput ............................................. ............................................................................................................................................... Pico and PicoGFX When you need simple control with a small footprint, the Pico family of controllers offers a practical solution that’s easy on your budget. Performing simple logic, timing, counting, and realtime clock operations, Pico and PicoGFX controllers provide you with more options than ever. • Pico: Simple, flexible control in a small package. Backwards-compatible programming, text messaging on the 12-point processor and additional power supply options. Up to 28 lines of ladder logic, and expansion capabilities up to 40 points of I/O. • PicoGFX: Displays text, date, time and custom bitmaps on its 70mm, backlit graphic display. Modular design lets you mount the display on the outside of your panel, while the controller and I/O are housed within the panel. Flexible for a wide variety of applications (expandable to 272 points of I/O). Can be DIN-rail or thrupanel mounted. Pico controllers are easily programmed with either PicoSoft Pro software (for PicoGFX; backwardcompatible for standard Pico controllers) or PicoSoft (for standard controllers). It couldn’t be simpler: one software package and one interface cover all the functions required. ............................................. ............................................................................................................................................... MicroLogix The MicroLogix family of micro controllers offers a breadth of options. With four controller types to choose from, you’ll be sure to find the controller with just the right functionality at the right price. • MicroLogix 1000: Small and compact with up to 32 points of I/O. • MicroLogix 1100: New controller features online editing, an embedded LCD, and an EtherNet/IP port for peer-to-peer messaging. • MicroLogix 1200: Features expansion I/O, compatible instruction set and programming software, and large non-volatile memory. With the 1200R model, gain a programming/HMI port in addition to the Channel 0 communications port for an inexpensive means to program the controller using a personal computer. • MicroLogix 1500: Most powerful member of the MicroLogix family. Removable processor, base units with embedded I/O, power supply and expansion through 1769 Compact I/O blocks. All MicroLogix controllers are programmed with industry-leading RSLogix 500 software, and are DIN-rail and panel mountable, as well as UL listed, C-UL certified, and Class 1, DIV. 2 and CE compliant. ............................................. ............................................................................................................................................... SLC The SLC 500 small, chassis-based, modular family of programmable controllers and I/O is designed with your smaller to mid-sized automation applications in mind. The SLC 500 system provides powerful, reliable, performance, without the additional capacity, features and associated costs of a full-size PLC. The SLC 500 processors offer a wide range of choices in memory (from 1 K to 64K), chassis (4,7,10, or 13 slot), instruction set, power supplies and built-in network capabilities, so you can tailor your control system to exactly meet your application requirements. The family includes five processor models: the 5/01, 5/02, 5/03, and 5/05. Choose from over 60 I/O modules to control digital, analog, and temperature signals. Like the MicroLogix family, SLC 500 controllers are programmed with RSLogix 500 programming software. ............................................. ............................................................................................................................................... PLC5 Flexibility. Reliability. Compatibility. At the center of thousands of control solutions, you’ll find a PLC-5 controller. A PLC-5 solution provides flexibility in programming, networking, I/O modules and a choice of controllers to suit your requirements. In addition, with a Mean Time Between Failure (MTBF) rating better than any comparable programmable controller, the rugged PLC-5 offers a high reliability solution. From simple systems comprised of stand-alone processors and I/O modules in a single chassis to complex applications with multiple networked processors and distributed I/O, the PLC-5 offers a wide range of benefits: • Rugged design and demonstrated performance in the most demanding applications • Proven solutions for large sequential control applications • Improved productivity with easy-to-use Microsoft Windows programming • System expandability with NetLinx Open Network Architecture • Common look and feel of product and programming tools saves spare parts and training. ............................................. ............................................................................................................................................... GuardPLC GuardPLC safety controllers have a proven track record of safety and performance. With four types of controllers to choose from, you’re sure to find a safety controller that meets your requirements. • GuardPLC 1200: Safety rated, high performance, compact Programmable Electronic System (PES). Complies with the requirements for Category 4 and SIL 3 safety applications. Includes a power supply, CPU, watchdog, 20 digital inputs, 8 digital outputs, 2 high-speed counters, and communication ports, incorporated in a rugged plastic housing. • GuardPLC 1600: Mainstream, cost-effective safety PLC offers a built-in, 4-port Ethernet switch and digital I/O (20 safety-rated inputs and 8 Category 4 outputs). The fastest safety PLC in the industry (10 ms throughput). Utilize the DeviceNet Safety Scanner to allow GuardPLC 1600 and 1800 to communicate over DeviceNet Safety networks. • GuardPLC 1800: All the features of GuardPLC 1600 plus analog inputs and highspeed counters for specialized applications such as emergency shut down, flame control, and amusement park ride control. Eight safety-rated analog inputs and 2 safety-rated high-speed counters allow the GuardPLC 1800 to expand beyond digital safety devices and sense field temperatures, pressure, speed, and motion. • GuardPLC 2000: Modular, chassis-based safety controller can provide as many as 144 digital inputs and 96 digital outputs. ............................................. ............................................................................................................................................... บริษัท ไทยเทคนิคอีเล็คตริค มีนบุรี จำกัด 26/49-50 หมู่ 13 ถนนสุวินทวงศ์ แขวงแสนแสบ เขตมีนบุรี กรุงเทพฯ 10510 โทรศัพท์ 02)919-4686-90 โทรสาร (02)917-3680, 02)9194691 Web Site: www.thaimin.co.th E-mail: kane@thaimin.co.th, sanya@thaimin.co.th
